OpenLDAP

配置OpenLDAP

请参考我的另一篇文档实战OpenLDAP

查看OpenLDAP是否安装

[root@linux src]# rpm -aq |grep openldap
openldap-devel-2.0.27-8
openldap-servers-2.0.27-8
openldap-clients-2.0.27-8
openldap-2.0.27-8


配置/etc/ldap.conf

vi /etc/ldap.conf
# Your LDAP server. Must be resolvable without using LDAP.
host 127.0.0.1

# The distinguished name of the search base.
#base dc=example,dc=com
base dc=example,dc=net


配置.schema

[root@linux src]# cp authldap.schema qmail.schema /etc/openldap/schema/
[root@linux src]# ls /etc/openldap/schema/
authldap.schema        inetorgperson.schema          misc.schema.default
corba.schema           inetorgperson.schema.default  nis.schema
corba.schema.default   java.schema                   nis.schema.default
core.schema            java.schema.default           openldap.schema
core.schema.default    krb5-kdc.schema               openldap.schema.default
cosine.schema          krb5-kdc.schema.default       qmail.schema
cosine.schema.default  misc.schema                   redhat
[root@linux src]#


配置/etc/openldap/slapd.conf

[root@linux src]# vi /etc/openldap/slapd.conf

include         /etc/openldap/schema/core.schema
include         /etc/openldap/schema/cosine.schema
include         /etc/openldap/schema/inetorgperson.schema
include         /etc/openldap/schema/nis.schema
include         /etc/openldap/schema/redhat/rfc822-MailMember.schema
include         /etc/openldap/schema/redhat/autofs.schema
include         /etc/openldap/schema/redhat/kerberosobject.schema
# courier imap
include /etc/openldap/schema/authldap.schema
# postfix qmail
include /etc/openldap/schema/qmail.schema

#prevents user froom looking at passwords
access to attr=userpassword,clearpassword
by anonymous auth
by self write
by dn="cn=admin,dc=example,dc=net" write
by dn="cn=courier,dc=example,dc=net" read
by * none
#files need access to this
access to attr=accountstatus
by dn="cn=admin,dc=example,dc=net" read
by dn="cn=courier,dc=example,dc=net" read
access to *
by dn="cn=admin,dc=example,dc=net" write
by users read
by self write
by * none

#######################################################################
# ldbm database definitions
#######################################################################

database       ldbm
#suffix         "dc=my-domain,dc=com"
suffix          "dc=example,dc=net"
#suffix         "o=My Organization Name,c=US"
#rootdn         "cn=Manager,dc=my-domain,dc=com"
rootdn          "cn=Manager,dc=example,dc=net"
#rootdn         "cn=Manager,o=My Organization Name,c=US"
# Cleartext passwords, especially for the rootdn, should
# be avoided.  See slappasswd(8) and slapd.conf(5) for details.
# Use of strong authentication encouraged.
# rootpw                secret
# rootpw         {crypt}ijFYNcSNctBYg
rootpw			 {crypt}$1$tKdtixgz$y38ohV/5h3DBOLxMaF6Ai/


crypt 密码产生很简单,很多语言里都有crypt(key,salt)函数,不过最简单的办法是,使用UNIX Shadow 密码,

[root@linux src]# cat /etc/shadow
root:$1$tKdtixgz$y38ohV/5h3DBOLxMaF6Ai/:12361:0:99999:7:::
bin:*:12361:0:99999:7:::
daemon:*:12361:0:99999:7:::
adm:*:12361:0:99999:7:::
lp:*:12361:0:99999:7:::
sync:*:12361:0:99999:7:::
shutdown:*:12361:0:99999:7:::
halt:*:12361:0:99999:7:::
mail:*:12361:0:99999:7:::
news:*:12361:0:99999:7:::
uucp:*:12361:0:99999:7:::
operator:*:12361:0:99999:7:::
games:*:12361:0:99999:7:::
gopher:*:12361:0:99999:7:::
ftp:*:12361:0:99999:7:::
nobody:*:12361:0:99999:7:::
rpm:!!:12361:0:99999:7:::
vcsa:!!:12361:0:99999:7:::
nscd:!!:12361:0:99999:7:::
sshd:!!:12361:0:99999:7:::
rpc:!!:12361:0:99999:7:::
rpcuser:!!:12361:0:99999:7:::
nfsnobody:!!:12361:0:99999:7:::
mailnull:!!:12361:0:99999:7:::
smmsp:!!:12361:0:99999:7:::
pcap:!!:12361:0:99999:7:::
apache:!!:12361:0:99999:7:::
squid:!!:12361:0:99999:7:::
webalizer:!!:12361:0:99999:7:::
xfs:!!:12361:0:99999:7:::
named:!!:12361:0:99999:7:::
ntp:!!:12361:0:99999:7:::
gdm:!!:12361:0:99999:7:::
amanda:!!:12361:0:99999:7:::
canna:!!:12361:0:99999:7:::
mysql:!!:12361:0:99999:7:::
postgres:$1$84N0N0OR$UMZvKUpUZ1/iZOSet9b49.:12416:0:99999:7:::
pvm:!!:12361:0:99999:7:::
desktop:!!:12361:0:99999:7:::
radvd:!!:12361:0:99999:7:::
guest:!!:12362:0:99999:7:::
cvs:$1$otg8oROn$3iO2.cifZBp.RLjeKFVqS/:12368:0:99999:7:::
cvsroot:$1$KrwdCtt0$DO7CRXweQhRtmVSIwGEUe/:12368:0:99999:7:::
chen:$1$IFyZtPDW$aofwx1MF87m.01WtGv7cq0:12492:0:99999:7:::
ming:$1$55wV30qQ$xzJULQ4dUQZTe8dykc4nh/:12398:0:99999:7:::
axia:$1$3y5Cq/g4$2lPGV6o11pSy0lmjF54860:12451:0:99999:7:::
crm:$1$wWh6t77G$0UNVYs/EOeIbJyBeEySj/1:12472:0:99999:7:::
ldap:!!:12520::::::
[root@linux src]#


我上面使用的密码({crypt}$1$tKdtixgz$y38ohV/5h3DBOLxMaF6Ai/),就是root的密码

注意事项 [1]

启动OpenLDAP

[root@linux src]# service ldap
Usage: /etc/init.d/ldap {start|stop|restart|status|condrestart}
[root@linux src]# service ldap start
Starting slapd:                                            [  OK  ]
[root@linux src]#


Notes

[1]

  • OpenLDAP默认使用ldbm数据库,你也可以使用Berkeley DB(bdb)

  • 在很多LDAP文档中,一些用户喜欢将LDAP管理员用户rootdn "cn=Manager,dc=example,dc=net" 改为"cn=admin,dc=example,dc=net" 或者 "cn=root,dc=example,dc=net" 其实这改成什么都是一样的,与权限无关。

  • 不要使用明文(rootpw secret)不安全,rootpw 前面不能有空格,否则提示ldap_bind: Invalid credentials

  • 如果你想使用更复杂的加密算法,可以参考我的另一篇文章《Pure-FTPd + LDAP + MySQL + PGSQL + Virtual-Users + Quota How To》 (第二版)2003-07-24
